ETA2892E8A ESOP-8 40V/3A，強(qiáng)制PWM模式，同步降壓轉(zhuǎn)換器

　　40V/3A, Forced PWM Mode, Synchronous Step-Down Converter

　　The ETA2892 is a high-efficiency and high-frequency DC-to-DC step-down switching regulator, capable of delivering up to 3A of output current. The device operates with input voltage from 3.6V to 40V, making the ETA2892 ideal for wide input voltage range power conversion.

　　Features

　　Wide Input Voltage Range 3.6V-40V

　　Capable of Delivering 3A Output

　　Current Mode Control

　　Programmable Switching Frequency

　　Forced PWM Mode

　　Low Rdson Internal Power FETs

　　Thermal Shutdown and UVLO Protection

　　Available in ESOP8 Package

　　Applications

　　Vehicle Electrical Devices

　　Smart Home

　　Surveillance
